Shock-Proof Memory (Approximately 10 Seconds)

Instant Start

When the PLAY button is pressed, audio starts instantly.

Auto Cue

After a track is selected, it is automatically cued to the point where audio starts rather than where the track starts. The level at which sound is first detected can be set between -36 and -48 dB (3 steps).

Play Mode and Finish Mode

1) Play mode

• Continuous: Play a whole disc.
• Single: Play a track.

2) Finish mode (Stop, Next, Recue)

This function is available when single or continuous playback is selected.

• Stop: Stop after a track or disc is finished playing.
• Next: Standby at the beginning of the next track after finishing the current track being played.
• Recue: After finishing the current track being played, standby at the point where you started playback.

CD-R/RW Playback Compatibility

MP3 Playback

• Folder/Title search
• ±12 Percent playback speed controllable on MP3
• Folder repeat playback

CD TEXT

Rotary Track Select Knob (Easy Track Selection)

Tracks can be selected quickly by turning the knob left or right. Pushing the knob in while turning will increment tracks by ten, making access to high number tracks fast and simple.

Adjustable XLR Active Balanced Stereo Output

Playback Speed Control

• The long stroke sliding fader adjusts the play speed of CDs or MP3 discs by ±12.0 percent in increments of 0.1 percent. This pitch control can be turned off for normal playback by pressing the pitch button.
• Pitch lock function: When pressing the pitch button again while pitch control mode is on and the pitch display is lit, you cannot change playback speed even if you move the sliding fader.
• Apart from pitch control on the front panel, playback speed can also be adjusted using a preset function that allows the speed to be increased by up to ±3.0 percent in increments of 0.2 percent. When this preset function is engaged, pitch control on the front panel is disabled.

Program Play (Maximum 99 Tracks)

- Three different programs can be stored in nonvolatile memory.

- The unit incorporates a memory function that boots the unit up automatically in the program mode when a programmed disc is inserted.

End Monitor

When this button is pressed while in standby mode, the end of the selected track is reviewed. The review duration can be preset between 5 and 35 seconds. While in continuous mode, the unit plays the final portion of the last track on the disc.

End of Message (EOM)

At the end of a track, the FL display flashes, providing a visual warning to the operator that the track will end shortly.  The point at which the EOM warning begins can be preset within a range of 0 to 60 seconds, seven steps.

Power-On Playback

When the unit is powered up:

1) Play the entire disc from the first track of the disc

2) Play the program sequence from the beginning

Next-Track Reserve

Turning the track select knob during playback reserves the next track to be played back. After the current track has finished playing back, the unit continues by playing back the reserved track.

Search Accuracy (One Frame = 1/75 Second—CD Only)

RS-232 Serial Port AMX/CRESTRON compatible)

Parallel (D-Sub 25-Pin)

When connected to an external controller, the DN-C635 allows users to use play, pause, and conduct other simple functions easily by contact closure control.

Fader Start

The parallel remote (D-sub 25-pin) connector allows fader start operation from a mixing console. You can select fader start mode as follows:

Start Only - Player starts when fader switch is turned on.

Start, Pause - Player starts when fader switch is turned on; player pauses when fader switch is turned off.

Sleep Function

This function increases drive life by shutting down the servo systems of the transport if a button is not pressed within the time specified. The sleep time can be specified in the preset menu or defeated.

Function Preset

Three different function presets can be stored into a non-volatile memory via buttons operated on the front panel (“ * ” indicates the default setting).
